POP Rivets, Countersunk, Stainless Steel 304, 4-2C 1/8" x 1/8" Gap (0.062 - 0.125)

1/8" (#4C)

1/8" or #4C (Rivet Sizing Chart)
Used in a countersunk hole to create a flat surface
Connect two materials quickly and efficiently
304 Stainless steel flat rivets are used in corrosive environments
Comprised of a hat and mandrel
Commonly used for:
- Sliding Tracks
- Rollers

Stainless Steel Open End Countersunk Blind Rivet Spec Sheet

Product number: 11970002

Print this page

Specifications

Additional Sizing Info: IFI Grade 50
Color: Silver
Condition: New
Corrosion Resistant: Yes
Countersink: 120 Degree
Diameter: 1/8"
Drill (Hole) Size: #30
Head Type: Flat Head (Rivet)
Rivet Diameter Facet: #4 (1/8")
Flange Diameter Nominal: 0.226
Grade: 304
Head Height Max: 0.032"
Head Style: Countersunk
Length: 1/8"
Mandrel Diameter Nominal: 0.076
Material: Stainless Steel
Nominal Size: #4
Part Number: 717029208200
Product Type: Countersunk POP Rivets (Blind Rivets) Open End
Rivet Diameter: (#4) 1/8" (.125)
Shear (lbs): 420
Size System: US
Size Type: Regular
System of Measurement: Inch
Tensile PSI: 530 lb
Tolerance (IFI): Actual measurements may vary slightly +/- depending on production run within IFI Tolerances
USA Made: Yes
Weight: 1 lb

Resources Rivet Size Chart Stainless Countersunk Rivet Specs

Select Size/SKU & Quantity

6 Available Sizes

SIZE/SKU	Review Volume Pricing*	Enter Any Qty
4-2C, 1/8" x 1/8" Grip (0.020 - 0.125) 11970002	1 $0.08 ($0.08/ea) 100 $7.00 ($0.07/ea) 1000 $60.00 ($0.06/ea)	Quantity for POP Rivets, Countersunk, Stainless Steel 304, 4-2C 1/8" x 1/8" Gap (0.062 - 0.125) $0.00
4-3C, 1/8" x 3/16" Grip (0.126 - 0.187) 11970018	1 $0.08 ($0.08/ea) 100 $7.00 ($0.07/ea) 1000 $60.00 ($0.06/ea)	Quantity for POP Rivets, Countersunk, Stainless Steel 304, 4-3C 1/8" x 3/16" Gap (0.126 - 0.187) $0.00
4-4C, 1/8" x 1/4" Grip (0.118 - 0.250) 11970034	1 $0.12 ($0.12/ea) 100 $10.00 ($0.10/ea) 1000 $90.00 ($0.09/ea)	Quantity for POP Rivets, Countersunk, Stainless Steel 304, 4-4C 1/8" x 1/4" Gap (0.118 - 0.250) $0.00
4-5C, 1/8" x 5/16" Grip (0.251 - 0.312) 11970050	1 $0.08 ($0.08/ea) 100 $7.00 ($0.07/ea) 1000 $60.00 ($0.06/ea)	Quantity for POP Rivets, Countersunk, Stainless Steel 304, 4-5C 1/8" x 5/16" Gap (0.251 - 0.312) $0.00
4-6C, 1/8" x 3/8" Grip (0.313 - 0.375) 11970066	1 $0.12 ($0.12/ea) 100 $10.00 ($0.10/ea) 1000 $90.00 ($0.09/ea)	Quantity for POP Rivets, Countersunk, Stainless Steel 304, 4-6C 1/8" x 3/8" Gap (0.313 - 0.375) $0.00
4-8C, 1/8" x 1/2" Grip (0.376 - 0.500) 11970082	1 $0.12 ($0.12/ea) 100 $10.00 ($0.10/ea) 1000 $90.00 ($0.09/ea)	Quantity for POP Rivets, Countersunk, Stainless Steel 304, 4-8C 1/8" x 1/2" Gap (0.376 - 0.500) $0.00
