What are Anchors for Steel?
Anchors for steel are drill free hangers that clamp to structural steel so you can attach threaded rod without drilling or welding. Our vertical steel hangers with coupler create a fast, secure connection for HVAC, electrical, fire protection, and general MEP supports.
How do vertical steel hangers with coupler work?
The hanger clamps to the steel flange and includes an integrated coupler. Tighten the set screw per the instructions until the body grips the steel, then thread in your rod for a stable, vertical drop.
When should I use Anchors for Steel?
- Overhead supports where drilling the beam is not allowed or practical
- HVAC duct, cable tray, sprinkler mains, and pipe hangers
- Retrofits that need clean, low impact installation on existing steel
Sizing and fit for Anchors for Steel
- Choose a hanger sized for your threaded rod (for example 1/4 in or 3/8 in) and the steel flange thickness it will clamp to
- Verify allowable load, flange range, and required torque from the product sheet
- Use the included/integrated coupler to join directly to your rod
Materials and finishes
Zinc plated steel
Durable, corrosion resistant finish for most indoor applications.
Stainless options
Select when added corrosion resistance is required (when available).
Installation tips
- Position the hanger square to the beam flange
- Tighten the set screw to the specified torque for full holding power
- Do not install on damaged, painted, or contaminated surfaces that could reduce grip
- Confirm edge clearance and rod alignment to keep loads vertical
Best practices and safety
- Follow all rated load limits and local codes
- Do not exceed the listed flange thickness or spacing guidelines
- Inspect clamps periodically in vibration prone areas
FAQs about Anchors for Steel
Quick answers for selection, sizing, and safe installation on structural steel.
- What are anchors for steel used for?
They provide a drill free way to hang threaded rod from steel beams for duct, pipe, cable tray, and sprinkler supports.
- Do I need to drill the beam?
No. These hangers clamp to the flange and use an integrated coupler so you can attach rod without drilling or welding.
- How do I choose the right size?
Match the rod size you plan to use and make sure the clamp’s flange range covers your beam flange thickness. Check the allowable load.
- What torque should I use on the set screw?
Use the torque value listed on the product instructions to achieve full holding power without damaging the steel.
- Can these be used outdoors?
Zinc plated versions are for interior use. For wet or corrosive areas, choose stainless options if available and follow local codes.
- Will they work on sloped or uneven steel?
Install on flat, clean flanges with the hanger seated square and the rod vertical. Do not use on tapered or damaged edges unless the product specifically allows it.
- How much weight can a steel hanger support?
Capacity varies by model, flange engagement, and orientation. Always follow the load rating on the product sheet for your exact hanger.
