Two Way Reversible Lock Nuts, Stainless Steel 316, 1/4"-20
All Metal Centerlock Nuts in 316 Stainless Steel
| Quantity | Unit price |
|---|---|
| To 99 |
$0.60*
|
| To 999 |
$0.55*
|
| From 1000 |
$0.45*
|
- Across Flats (Width): Max 0.438 - Min 0.428
- Color: Silver
- Corrosion Resistant: Yes
- Diameter: 1/4"
- Drive Style: External Hex
- Thread Direction: Right Hand
- Fit: 2B
- Grade: 316
- Internal Thread: 1/4/2020
- Marine Grade: Yes
- Material: Stainless Steel
- Product Type: Two Way Reversible Lock Nut
- System of Measurement: Inch
- Thread Direction: Right Hand
- Thread Pitch: 20 Per Inch
- Thread Size: 1/4"-20
- Thread Standard: UNC
- Thread Type: Coarse
- Tolerance (IFI): Actual measurements may vary slightly +/- depending on production run within IFI Tolerances
- Marine Grade 316 Stainless Steel
- Highly Corrosion Resistant - Suitable for Saltwater Environments
- Can be used either top up or top down
- Can be identified by indentations on the outside which distorts the internal threads to increase resistance on the mating part
- Also referred to as two way lock nuts or center lock nuts, which are a kind of distorted thread locknut
Nut Size
Width Across Flats
Thickness
1/4"
Max 0.438 - Min 0.428
Max 0.226 - Min 0.212
5/16"
Max 0.500 - Min 0.489
Max 0.273 - Min 0.258
3/8"
Max 0.562 - Min 0.551
Max 0.337 - Min 0.320
1/2"
Max 0.750 - Min 0.736
Max 0.448 - Min 0.427
5/8"
Max 0.938 - Min 0.922
Max 0.559 - Min 0.535
3/4"
Max 1.125 - Min 1.088
Max 0.665 - Min 0.617
Product number:
6002-006-002
