1/8" (#4) POP Rivet 304 Stainless Steel

1/8" Stainless Steel Open End Dome Head Blind POP Rivets

POP Rivet, or Blind Rivet, in 304 Stainless Steel


  • 1/8" or #4 (Rivet Sizing Chart)
  • Domed head rivets are used when there is no access to the blind side of the two materials
  • Most common rivet
  • IFI 114 Compliant
  • Used to join two materials together quickly
  • After mandrel breaks off domed head is left exposed
  • 304 Stainless steel dome head rivets are suitable for corrosive environments

Stainless Steel Open End Blind Rivet Spec Sheet

Select Products Below See Product Specifications

NA = "Not Sold In Single Quantity"

Size
Select Package Quantity
SubTotal
POP Rivet 304 SS - 4-1, 1/8" x 1/16" Grip (0.032 - 0.062)
SKU #11930002
POP Rivet 304 SS - 4-1, 1/8" x 1/16" Grip (0.032 - 0.062)
SKU #11930002
1
$0.12 (0.12/ea)
100
$10.00 (0.1/ea)
1000
$90.00 (0.09/ea)
Subtotal: $0.00 /
POP Rivet 304 SS - 4-2, 1/8" x 1/8" Grip (0.063 - 0.125)
SKU #11930018
POP Rivet 304 SS - 4-2, 1/8" x 1/8" Grip (0.063 - 0.125)
SKU #11930018
1
$0.13 (0.13/ea)
100
$8.00 (0.08/ea)
1000
$70.00 (0.07/ea)
Subtotal: $0.00 /
POP Rivet 304 SS - 4-3, 1/8" x 3/16" Grip (0.126 - 0.187)
SKU #11930034
POP Rivet 304 SS - 4-3, 1/8" x 3/16" Grip (0.126 - 0.187)
SKU #11930034
1
$0.15 (0.15/ea)
100
$8.00 (0.08/ea)
1000
$70.00 (0.07/ea)
Subtotal: $0.00 /
POP Rivet 304 SS - 4-4, 1/8" x 1/4" Grip (0.188 - 0.250)
SKU #11930050
POP Rivet 304 SS - 4-4, 1/8" x 1/4" Grip (0.188 - 0.250)
SKU #11930050
1
$0.15 (0.15/ea)
100
$8.00 (0.08/ea)
1000
$70.00 (0.07/ea)
Subtotal: $0.00 /
POP Rivet 304 SS - 4-5,1/8" x 5/16" Grip (0.251 - 0.321)
SKU #11930066
POP Rivet 304 SS - 4-5,1/8" x 5/16" Grip (0.251 - 0.321)
SKU #11930066
1
$0.17 (0.17/ea)
100
$10.00 (0.1/ea)
1000
$90.00 (0.09/ea)
Subtotal: $0.00 /
POP Rivet 304 SS - 4-6, 1/8" x 3/8" Grip (0.313 - 0.375)
SKU #11930082
POP Rivet 304 SS - 4-6, 1/8" x 3/8" Grip (0.313 - 0.375)
SKU #11930082
1
$0.17 (0.17/ea)
100
$10.00 (0.1/ea)
1000
$90.00 (0.09/ea)
Subtotal: $0.00 /
POP Rivet 304 SS - 4-8, 1/8" x 1/2" Grip (0.376 - 0.500)
SKU #11930098
POP Rivet 304 SS - 4-8, 1/8" x 1/2" Grip (0.376 - 0.500)
SKU #11930098
1
$0.21 (0.21/ea)
100
$12.00 (0.12/ea)
1000
$110.00 (0.11/ea)
Subtotal: $0.00 /
POP Rivet 304 SS - 4-10, 1/8" x 5/8" Grip (0.501 - 0.625)
SKU #11930114
POP Rivet 304 SS - 4-10, 1/8" x 5/8" Grip (0.501 - 0.625)
SKU #11930114
1
$0.20 (0.2/ea)
100
$17.00 (0.17/ea)
1000
$150.00 (0.15/ea)
Subtotal: $0.00 /




Product Specifications
Additional Sizing Info
IFI Grade 50
Color
Silver
Corrosion Resistant
Yes
Drill (Hole) Size
#30
Flange Diameter Nominal
0.250"
Grade
304
Head Height Max
0.040"
Head Style
Dome
Mandrel Diameter Nominal
0.076"
Material
Stainless Steel
Nominal Size
4
Product Type
POP Rivets (Blind Rivets) Open End
Rivet Diameter
(#4) 1/8" (.125)
Shear (lbs)
420
System of Measurement (Unit)
Inch
Tolerance (IFI)
Actual measurements may vary slightly +/- depending on production run within IFI Tolerances
USA Made
Yes
