#10 Phillips Pancake Head Self Drilling Sheet Metal Screws 410 Stainless Steel
Phillips Pancake Head Self Drilling Screws 410 Stainless Steel #10



Alternative Views:

Stainless Steel Phillips Pancake Head Self Drilling Screws

Diameter - Thread Pitch: #10-16

Phillips Pancake Head Self Drilling screws are made of hardened 410 Stainless Steel and have a sheet metal thread with a self driller cutting (TEK) point to pierce through 20 to 14 gauge metals. The higher the TEK number the larger the drill point to pierce heavier gauge metals. The heads use a Phillips driver #1, #2 or #3 depending on the size of the screw.

Stainless Steel Phillips Pancake Head TEK Screws have a self drilling point to aid in the installation of these screws into harder materials. Additionally, these screws are made of hardened 410 Stainless Steel which is harder than the material that is being fastened, easing the installation process, and allowing installation into sheet metal or metal studs.

Product Specifications:
Phillips Pancake Head Self Drilling Screws
Body Diameter: (#10) Max 0.194" - Min 0.188"
Thread Pitch: 16 Per Inch (Coarse)
Point Type: TEK-3 (0.353)
Thread Direction: Right Hand
Material: 410 Stainless Steel
Driver Max RPM: 2,300
ANSI B18.6.4
Tensile: 180,000 PSI Heat Treated
Hardness: 40 Rockwell C
Diameter - Thread Pitch x Length from Underside of Head
Product Specifications may vary slightly +/- depending upon production run
within IFI Tolerances


Item# Item Name Our Price Qty Add
12732000-002 Phillips Pancake Head Self Drill Screws 410 Stainless Steel #10 x 1"- Qty-1
$0.26
12732000-004 Phillips Pancake Head Self Drill Screws 410 Stainless Steel #10 x 1"- Qty-25
$5.95
12732000-006 Phillips Pancake Head Self Drill Screws 410 Stainless Steel #10 x 1"- Qty-100
$21.66
12732000-008 Phillips Pancake Head Self Drill Screws 410 Stainless Steel #10 x 1"- Qty-250
$51.43
12732000-010 Phillips Pancake Head Self Drill Screws 410 Stainless Steel #10 x 1"- Qty-1000
$194.91
12732000-012 Phillips Pancake Head Self Drill Screws 410 Stainless Steel #10 x 1-1/2"- Qty-1
$0.26
12732000-014 Phillips Pancake Head Self Drill Screws 410 Stainless Steel #10 x 1-1/2"- Qty-25
$5.91
12732000-016 Phillips Pancake Head Self Drill Screws 410 Stainless Steel #10 x 1-1/2"- Qty-100
$21.51
12732000-018 Phillips Pancake Head Self Drill Screws 410 Stainless Steel #10 x 1-1/2"- Qty-250
$51.09
12732000-020 Phillips Pancake Head Self Drill Screw 410 Stainless Steel #10 x 1-1/2"- Qty-1000
$193.61
12732000-022 Phillips Pancake Head Self Drill Screws 410 Stainless Steel #10 x 2"- Qty-1
$0.28
12732000-024 Phillips Pancake Head Self Drill Screws 410 Stainless Steel #10 x 2"- Qty-25
$6.59
12732000-026 Phillips Pancake Head Self Drill Screws 410 Stainless Steel #10 x 2"- Qty-100
$23.97
12732000-028 Phillips Pancake Head Self Drill Screws 410 Stainless Steel #10 x 2"- Qty-250
$56.92
12732000-030 Phillips Pancake Head Self Drill Screws 410 Stainless Steel #10 x 2"- Qty-1000
$215.70
