3/8" Zinc Plated Phillips / Flat Head Sleeve Anchors

3/8" Zinc Plated Phillips / Flat Head Sleeve Anchors

Diameter: 3/8"


3/8" Zinc Plated Phillips / Flat Head Sleeve Anchors

  • Phillips/Slotted head combo allows for installation with a Phillips or flat head screwdriver
  • 360 degree expansion provides consistent and reliable holding values in a wide range of base materials
  • Pre-assembled and ready to install; no need to purchase bolts, nuts, and washers separately for a convenient application process
  • Anchor size matches recommended drill bit size for simple, fast installation and consistent optimal results
  • Zinc plated carbon steel construction suitable for most dry environment applications

3/8" Zinc Plated Phillips / Flat Head Sleeve Anchors, also known as 3/8 Flat Phillips Sleeve Anchors Zinc Plated, are versatile expanding anchors designed for medium to heavy-duty fastening in concrete, block, brick, and stone. The combination Phillips/slotted head allows for installation with either a Phillips head or flat head screwdriver.

To install these 3/8" Phillips flat head sleeve anchors, drill the recommended 3/8" diameter pilot hole, insert the anchor through the fixture and into the base material, then tighten the head to expand the outer sleeve for a secure hold. Zinc plating on the 3/8" carbon steel sleeve anchor provides good corrosion resistance for use in most dry interior applications. For maximum corrosion resistance, consider hot dipped galvanized or stainless steel options.

3/8 Flat Phillips Sleeve Anchor Zinc Plated anchors are commonly used for securing:

  • Electrical panels, disconnect switches, and transformers
  • Water and gas pipes
  • Cable trays and bus ducts
  • HVAC equipment
  • Shelving and racks
  • Elevator guide rails
  • Steel stairways and catwalks

Available Sizes:

  • 3/8" x 2-3/4" Zinc Plated Phillips / Flat Head Sleeve Anchor
  • 3/8" x 4" Zinc Plated Phillips / Flat Head Sleeve Anchor
  • 3/8" x 5" Zinc Plated Phillips / Flat Head Sleeve Anchor
  • 3/8" x 6" Zinc Plated Phillips / Flat Head Sleeve Anchor

Choose the 3/8" zinc plated sleeve anchor length to suit your fixture thickness and base material while ensuring minimum embedment requirements are met. These 3/8" Phillips flat head sleeve anchors provide a reliable, easy-to-install solution for a variety of medium to heavy-duty anchoring applications in concrete and masonry.

Select Products Below See Product Specifications

NA = "Not Sold In Single Quantity"

Size
Select Package Quantity
SubTotal
Flat Head Combo Sleeve Anchor Zinc 3/8" x 5"
SKU #1082-012-0022
Flat Head Combo Sleeve Anchor Zinc 3/8" x 5"
SKU #1082-012-0022
1
$1.83 (1.83/ea)
25
$44.00 (1.76/ea)
100
$169.00 (1.69/ea)
1000
$1,670.00 (1.67/ea)
Subtotal: $0.00 /
Flat Head Combo Sleeve Anchor Zinc 3/8" x 2-3/4"
SKU #1082-012-0002
Flat Head Combo Sleeve Anchor Zinc 3/8" x 2-3/4"
SKU #1082-012-0002
1
$1.37 (1.37/ea)
25
$32.50 (1.3/ea)
100
$120.00 (1.2/ea)
1000
$1,030.00 (1.03/ea)
Subtotal: $0.00 /
Flat Head Combo Sleeve Anchor Zinc 3/8" x 4"
SKU #1082-012-0012
Flat Head Combo Sleeve Anchor Zinc 3/8" x 4"
SKU #1082-012-0012
1
$1.40 (1.4/ea)
25
$33.25 (1.33/ea)
100
$123.00 (1.23/ea)
1000
$1,050.00 (1.05/ea)
Subtotal: $0.00 /
Flat Head Combo Sleeve Anchor Zinc 3/8" x 6"
SKU #1082-012-0032
Flat Head Combo Sleeve Anchor Zinc 3/8" x 6"
SKU #1082-012-0032
1
$2.08 (2.08/ea)
25
$49.50 (1.98/ea)
100
$182.00 (1.82/ea)
1000
$1,560.00 (1.56/ea)
Subtotal: $0.00 /

Product Specifications
Drill (Hole) Size
3/8"
Drive Style
Phillips Slotted Combo
Finish
Zinc Plated
Head Diameter
0.700"
Head Height
Max 0.161 - Min 0.156
Head Style
Flat
Material
Steel
System of Measurement (Unit)
Inch
Thread Direction
Right Hand
Thread Pitch (Count)
16 Per Inch
Tolerance (IFI)
Actual measurements may vary slightly +/- depending on production run within IFI Tolerances
