#8-15 Square Drive Pan Head Sheet Metal Screws 18-8 Stainless Steel

#8-15 Stainless Steel Square Drive Pan Head Sheet Metal Screws

Diameter - Thread Pitch: #8-15

  • #8-15
  • Easily cut into soft materials
  • Fully threaded
  • Threads cut into material
  • Great for attaching metal equipment to wood
  • Strong retention in wood
  • Also known as Self Piercing Screws or Self Tapping Screws
  • Pan head - rounded top with an undercut (flat bottom) head
  • Square drive to prevent stripping at higher torque
  • Sizes listed below as: Diameter - Length
  • An 18-8 stainless steel square drive pan head sheet metal screw is corrosion and rust resistant
  • Great for fresh water moisture environments
Type A Sheet Metal Screw Thread Specifications
Select Products Below See Product Specifications
NA = "Not Sold In Single Quantity"

Size
Select Package Quantity
SubTotal
Square Drive Pan Head SMS 18-8 SS - #8 x 1/2"
SKU #3290002
Square Drive Pan Head SMS 18-8 SS - #8 x 1/2"
SKU #3290002
1
 NA
25
 $4.25 (0.17/ea)
100
 $8.00 (0.08/ea)
1000
 $70.00 (0.07/ea)
Subtotal: $0.00 /
Square Drive Pan Head SMS 18-8 SS - #8 x 5/8"
SKU #3290012
Square Drive Pan Head SMS 18-8 SS - #8 x 5/8"
SKU #3290012
1
 NA
25
 $5.00 (0.2/ea)
100
 $9.00 (0.09/ea)
1000
 $80.00 (0.08/ea)
Subtotal: $0.00 /
Square Drive Pan Head SMS 18-8 SS - #8 x 3/4"
SKU #3290022
Square Drive Pan Head SMS 18-8 SS - #8 x 3/4"
SKU #3290022
1
 NA
25
 $5.00 (0.2/ea)
100
 $10.00 (0.1/ea)
1000
 $90.00 (0.09/ea)
Subtotal: $0.00 /
Square Drive Pan Head SMS 18-8 SS - #8 x 1"
SKU #3290032
Square Drive Pan Head SMS 18-8 SS - #8 x 1"
SKU #3290032
1
 NA
25
 $5.00 (0.2/ea)
100
 $11.00 (0.11/ea)
1000
 $100.00 (0.1/ea)
Subtotal: $0.00 /
Square Drive Pan Head SMS 18-8 SS - #8 x 1-1/4"
SKU #3290042
Square Drive Pan Head SMS 18-8 SS - #8 x 1-1/4"
SKU #3290042
1
 NA
25
 $5.50 (0.22/ea)
100
 $14.00 (0.14/ea)
1000
 $120.00 (0.12/ea)
Subtotal: $0.00 /
Square Drive Pan Head SMS 18-8 SS - #8 x 1-1/2"
SKU #3290052
Square Drive Pan Head SMS 18-8 SS - #8 x 1-1/2"
SKU #3290052
1
 NA
25
 $6.00 (0.24/ea)
100
 $15.00 (0.15/ea)
1000
 $130.00 (0.13/ea)
Subtotal: $0.00 /
Square Drive Pan Head SMS 18-8 SS - #8 x 1-3/4"
SKU #3290062
Square Drive Pan Head SMS 18-8 SS - #8 x 1-3/4"
SKU #3290062
1
 NA
25
 $5.75 (0.23/ea)
100
 $19.00 (0.19/ea)
1000
 $170.00 (0.17/ea)
Subtotal: $0.00 /
Square Drive Pan Head SMS 18-8 SS - #8 x 2"
SKU #3290072
Square Drive Pan Head SMS 18-8 SS - #8 x 2"
SKU #3290072
1
 NA
25
 $7.00 (0.28/ea)
100
 $21.00 (0.21/ea)
1000
 $190.00 (0.19/ea)
Subtotal: $0.00 /
Square Drive Pan Head SMS 18-8 SS - #8 x 2-1/2"
SKU #3290082
Square Drive Pan Head SMS 18-8 SS - #8 x 2-1/2"
SKU #3290082
1
 NA
25
 $8.25 (0.33/ea)
100
 $25.00 (0.25/ea)
1000
 $220.00 (0.22/ea)
Subtotal: $0.00 /
Square Drive Pan Head SMS 18-8 SS - #8 x 3"
SKU #3290092
Square Drive Pan Head SMS 18-8 SS - #8 x 3"
SKU #3290092
1
 NA
25
 $13.25 (0.53/ea)
100
 $29.00 (0.29/ea)
1000
 $260.00 (0.26/ea)
Subtotal: $0.00 /

Frequently Used With

Square Power Bits - #2 - Length 2"
Square Power Bits - #2 - Length 2" 1050-600-0011
Square Power Bits - #2 - Length 2
1
 $1.05 (1.05/ea)
10
 $8.60 (0.86/ea)
25
 $19.75 (0.79/ea)
50
 $38.50 (0.77/ea)
Subtotal: $0.00 /
Square Power Bits Titanium Nitride - #2 x 2"
Square Power Bits Titanium Nitride - #2 x 2" 1050-602-0012
Square Power Bits Titanium Nitride - #2 x 2
1
 $4.84 (4.84/ea)
10
 $43.20 (4.32/ea)
25
 $103.25 (4.13/ea)
50
 $194.50 (3.89/ea)
Subtotal: $0.00 /
Product Specifications
ANSI
ANSI B18.6.4
Color
Silver
Corrosion Resistant
Yes
Diameter
#8
Drive Style
Internal Square
Elongation
30%
Grade
18-8
Hardness
100 Rockwell B
Head Diameter
Max 0.322 - Min 0.306
Head Height Max
0.096
Head Style
Pan
Material
Stainless Steel
Overall Head Height
Max 0.096 - Min 0.085
Point Type
A
Product Type
Sheet Metal Screws
Reduction
40%
Square Drive
#2
Standards Met
ANSI B18.6.4
System of Measurement (Unit)
Inch
Tensile PSI
100,000 - 125,000 PSI
Thread Diameter Major
(#8) 0.168" - 0.162"
Thread Diameter Minor
(#8) 0.123" - 0.116"
Thread Direction
Right Hand
Thread Pitch (Count)
15 Per Inch
Thread Standard
UNC
Thread Type
Coarse
Tolerance (IFI)
Actual measurements may vary slightly +/- depending on production run within IFI Tolerances
Yield PSI
55,000 - 75,000 PSI
