#14 (1/4") Slotted Hex Washer Head Sheet Metal Screws 18-8 Stainless Steel

#14-10 Stainless Steel Slotted Hex Washer Head Sheet Metal Screws

Diameter - Thread Pitch: #14-10


  • #14-10
  • Slotted Hexagon drive for use with a screwdriver, wrench or socket
  • Fully Threaded from tip to head
  • Integral washer at the top of the head
  • Type A point
  • 18-8 Stainless steel slotted hex washer sheet metal screws are rust resistant
  • While not universal, these screws are commonly used in license plates
  • NOTE: Sheet metal screws provide excellent retention in wood but are very difficult to remove

Select Products Below
See Product Specifications
Size:
Qty
Size
Select Package Quantity
SubTotal
Loading ...
Product Specifications
Across Flats (Width)
3/8" (Max 0.375 - Min 0.368)
Additional Sizing Info
Slotted Hex Washer Head Sheet Metal Screws
ANSI
B18.6.4
Class
2A
Corrosion Resistant
Yes
Drive Style
External Hex Slotted
Elongation
30%
Grade
18-8
Hardness
100 Rockwell B
Head Diameter
3/8", Max 0.375 - Min 0.367
Head Style
Hex Washer
Material
Stainless Steel
Point Type
A
Reduction
40%
Slotted Depth
Max 0.111 - Min 0.083
Slotted Drive
Max 0.075 - Min 0.064
System of Measurement (Unit)
Inch
Tensile PSI
100,000 - 125,000 PSI
Thread Diameter Major
(#14) 0.254" - 0.248"
Thread Diameter Minor
(#14) 0.185" - 0.178"
Thread Direction
Right Hand
Thread Pitch (Count)
10 Per Inch
Thread Standard
UNC
Thread Type
Coarse
Tolerance (IFI)
Actual measurements may vary slightly +/- depending on production run within IFI Tolerances
Washer OD
Max 0.520 - Min 0.480
Washer Thickness
Max 0.050 - Min 0.030
Wrench Size
3/8"
Yield PSI
55,000 - 75,000 PSI
