Click on a size/sku in the table to view product-specific details and specifications.

Specifications

  • Color (Duplicate): Black
  • Color: Black
  • Condition: New
  • Corrosion Resistant: Yes
  • Countersink: 82 Degree
  • Diameter: #12
  • Drive Style: Phillips
  • Head Type: Flat Head
  • Thread Direction: Right Hand
  • Thread Type: Coarse
  • Finish: Black Oxide
  • Fit: 2A
  • Grade: 18-8
  • Head Diameter: Max 0.438 - Min 0.389
  • Head Style: Flat
  • Length: 1/2"
  • Material (Duplicate): Black Oxide Stainless Steel
  • Material: Stainless Steel
  • Overall Head Height: Max 0.132 - Min 0.112 (From Bottom of Undercut to Top of Head)
  • Part Number: 618930233872
  • Phillips Drive: #2
  • Product Type: Machine Screws
  • Size System: US
  • Size Type: Regular
  • Standards Met: ANSI B1.1, ANSI B18.6.3
  • System of Measurement: Inch
  • Thread Diameter: (#12) Max 0.2150 - Min 0.2078
  • Thread Direction: Right Hand
  • Thread Pitch: 24 Per Inch
  • Thread Size: #12-24
  • Thread Standard: UNF
  • Thread Type: Fine
  • Tolerance (IFI): Actual measurements may vary slightly +/- depending on production run within IFI Tolerances
  • Weight: 1 lb
Select Size/SKU & Quantity
1 Available Sizes
SIZE/SKU Review Volume Pricing* Enter Any Qty
1016-78000000-001
1
$0.40 ($0.40/ea)
100
$25.00 ($0.25/ea)
1000
$230.00 ($0.23/ea)
$0.00

*Volume pricing available on select products. Products without quantity breaks are priced per unit.

Page Total: $0.00
