#4-40 Stainless Steel Phillips Flat Head Machine Screws
Diameter - Thread Pitch: #4-40
- 18-8 Stainless steel includes 303 and 304 stainless steel
- A machine screw is commonly identified by its small size
- Considered the fastener industry standard for stainless steel
- Flat head screws are made to sit flush against their installed material
- Corrosion and rust resistant
- Excellent in applications exposed to fresh water or moisture
#4-40 Stainless steel Phillips flat head machine screws are available in 18-8 stainless steel.
See Product Specifications
NA = "Not Sold In Single Quantity"
Select Package Quantity
Loading ...
Product Specifications
ANSI
ANSI B18.6.3
Class
2A
Color
Silver
Corrosion Resistant
Yes
Countersink
82 Degree
Diameter
#4
Drive Style
Phillips
Fit
Class 2A
Grade
18-8
Head Diameter
Max 0.225 - Min 0.195
Head Height Max
0.067
Head Style
Flat
Material
Stainless Steel
Overall Head Height
Max 0.067 - Min 0.055
Phillips Drive
#1
Product Type
Machine Screws
Standards Met
ANSI B18.6.3
System of Measurement (Unit)
Inch
Thread Direction
Right Hand
Thread Pitch (Count)
40 Per Inch
Thread Standard
UNC
Thread Type
Coarse
Tolerance (IFI)
Actual measurements may vary slightly +/- depending on production run within IFI Tolerances
