#6-32 Brass Threaded Inserts for Wood
E-Z Lok Number | Internal Thread Size: #400-006 | #6-32
#6-32 Brass Thread Inserts for Wood feature external knife threads provide superior holding power in hard and soft woods, particle board and all wood products.
- Use to prevent thread erosion or stripping
- Long pilot ensures straight driving into a drilled hole
- Install with screwdriver, bolt and nut or tapping head
Sizes Listed As:
E-Z Lok MPN, Internal Thread x Insert Length
See Product Specifications
See Product Video
NA = "Not Sold In Single Quantity"
Select Package Quantity
Loading ...
Product Specifications
Color
Yellow
Color May Vary
Color and sheen may vary
Corrosion Resistant
Yes
Diameter
#6
Drill (Hole) Size
1/4"
Drive Style
Slotted/E-Z Lok Drive Tool
External Thread
0.328
EZ Lok Drive Took
500-006
Head Style
No Head
Insert Length
0.375
Internal Thread
#6-32
Manufacturer Part Number
400-006
Material
Brass
Other
External Knife Thread
Pilot Hole
1/4"
Product Type
Thread Insert
System of Measurement (Unit)
Inch
Thread Direction
Right Hand
Thread Pitch (Count)
32 Per Inch
Thread Standard
UNC
Thread Type
Coarse
Tolerance (IFI)
Actual measurements may vary slightly +/- depending on production run within IFI Tolerances
