#6-32 | 316 Stainless Steel Phillips Oval Head Machine Screws

#6-32 | 316 Stainless Steel Phillips Oval Head Machine Screws

Diameter - Thread Pitch: #6-32

  • Countersunk head with a raised domed top
  • Used either with a nut or in a pre-tapped hole
  • A machine screw is commonly identified by its small size
  • Raised decorative head
  • Used to secure materials that may be tampered with
  • Ideal for saltwater moisture environments
  • Rust and corrosion resistant

#6-32 Phillips drive oval head machine screws are available in marine grade 316 stainless steel.

Select Products Below See Product Specifications
NA = "Not Sold In Single Quantity"

Size
Select Package Quantity
SubTotal
#6-32 x 3/8" | 316 Stainless Steel Phillips Oval Head Machine Screws
SKU #5106-002-002
#6-32 x 3/8" | 316 Stainless Steel Phillips Oval Head Machine Screws
SKU #5106-002-002
1
 $0.15 (0.15/ea)
100
 $10.00 (0.1/ea)
1000
 $90.00 (0.09/ea)
Subtotal: $0.00 /
#6-32 x 1/2" | 316 Stainless Steel Phillips Oval Head Machine Screws
SKU #5106-002-004
#6-32 x 1/2" | 316 Stainless Steel Phillips Oval Head Machine Screws
SKU #5106-002-004
1
 $0.36 (0.36/ea)
100
 $11.00 (0.11/ea)
1000
 $90.00 (0.09/ea)
Subtotal: $0.00 /
#6-32 x 3/4" | 316 Stainless Steel Phillips Oval Head Machine Screws
SKU #5106-002-006
#6-32 x 3/4" | 316 Stainless Steel Phillips Oval Head Machine Screws
SKU #5106-002-006
1
 $0.36 (0.36/ea)
100
 $12.00 (0.12/ea)
1000
 $100.00 (0.1/ea)
Subtotal: $0.00 /
#6-32 x 1" | 316 Stainless Steel Phillips Oval Head Machine Screws
SKU #5106-002-008
#6-32 x 1" | 316 Stainless Steel Phillips Oval Head Machine Screws
SKU #5106-002-008
1
 $0.36 (0.36/ea)
100
 $13.00 (0.13/ea)
1000
 $110.00 (0.11/ea)
Subtotal: $0.00 /
#6-32 x 2" | 316 Stainless Steel Phillips Oval Head Machine Screws
SKU #5106-002-010
#6-32 x 2" | 316 Stainless Steel Phillips Oval Head Machine Screws
SKU #5106-002-010
1
 $0.36 (0.36/ea)
100
 $19.00 (0.19/ea)
1000
 $160.00 (0.16/ea)
Subtotal: $0.00 /
Product Specifications
ANSI
ANSI B1.1
Color
Silver
Corrosion Resistant
Yes
Countersink
82 Degree
Diameter
#6
Drive Style
Phillips
Grade
316
Head Diameter
Max 0.279 - Min 0.244
Head Height Max
0.128
Head Style
Oval
Marine Grade
Yes
Material
Stainless Steel
Overall Head Height
Max 0.128 - Min 0.105
Phillips Drive
#1
Product Type
Machine Screws
Standards Met
ANSI B18.6.3
System of Measurement (Unit)
Inch
Thread Direction
Right Hand
Thread Pitch (Count)
32 Per Inch
Thread Standard
UNC
Thread Type
Coarse
Tolerance (IFI)
Actual measurements may vary slightly +/- depending on production run within IFI Tolerances
