Wedge Anchor, Hot Dipped Galvanized, 1/2"-13 x 2-3/4"
Diameter - Pitch: 1/2"-13
Quantity | Unit price |
---|---|
To 99 |
$1.77*
|
To 999 |
$1.36*
|
From 1000 |
$1.25*
|
- Across Flats (Width): 3/4" (Max 0.750 - Min 0.736)
- Color (Duplicate): Gray
- Color: Gray
- Condition: New
- Corrosion Resistant: Yes
- Diameter: 1/2"
- Drill (Hole) Size: 1/2"
- Drive Style: External Hex
- Head Type: No Head
- Thread Direction: Right Hand
- Thread Type: Coarse
- Finish: Hot Dip Galvanized
- Head Style: No Head
- Length: 2-3/4"
- Material (Duplicate): Hot Dipped Galvanized Steel
- Material: Steel
- Other: Listed As
- Part Number: 730656626254
- Pattern: Wedge Anchor
- Product Type: Wedge Anchors
- Size: 1/2"-13 x 2-3/4"
- Size System: US
- Size Type: Regular
- System of Measurement: Inch
- Thread Direction: Right Hand
- Thread Pitch: 13 Per Inch
- Thread Size: 1/2"-13
- Thread Standard: UNC
- Thread Type: Coarse
- Tolerance (IFI): Actual measurements may vary slightly +/- depending on production run within IFI Tolerances
- Weight: 1 lb
- Wrench Size: 3/4"
1/2"-13 Hot Dipped Galvanized Wedge Anchors are heavy-duty fasteners designed for securely anchoring large equipment and materials to concrete surfaces. These robust anchors provide exceptional holding power and corrosion resistance, making them suitable for demanding applications.
- Hot dipped galvanized coating offers enhanced protection against rust and corrosion in moist environments, ensuring long-term durability and reduced maintenance
- Molten Zinc bath finishing process forms a durable, bonded alloy coating for superior corrosion resistance
- Versatile anchors used to secure heavy equipment, large materials, industrial machinery, structural components, and more to concrete masonry surfaces
- Easy installation into pre-drilled holes using a carbide-tipped bit that meets ANSI standards
- Insert the non-threaded end into the hole and then strike it to expand the anchor, creating a strong, secure hold.
- Tighten the included nut and washer against the fixture to complete the installation.
- Available in a wide range of lengths to accommodate various application requirements
- High load-bearing capacity and consistent holding values ensure reliable performance and peace of mind
- Stamped with length identification for easy inspection after installation
- For optimal results, use only Hot Dip Galvanized fasteners together to prevent potential threading and durability issues
Available Lengths:
- 1/2 x 2-3/4"
- 1/2 x 3-3/4"
- 1/2 x 4-1/4"
- 1/2 x 5-1/2"
- 1/2 x 7"
- 1/2 x 8-1/2"
- 1/2 x 10"
The 1/2"-13 Hot Dipped Galvanized Concrete Wedge Anchor is a heavy-duty fastener used to secure large materials and equipment to concrete surfaces. It is also referred to as an anchor bolt or expansion wedge.
This type of anchor is essential for securing heavy items in place. It is a reliable choice for fastening large objects to concrete. These anchor bolts consist of an expansion wedge bolt, a hex nut, and a flat washer, working together to provide a strong, secure hold.
For 1/2" diameter anchors, the minimum embedment depth is 2-1/4". For anchors with a 1/2" diameter, the minimum embedment depth is 2-1/4".
You should space these anchors at least 10 anchor diameters apart for optimal performance. Additionally, place them 5 anchor diameters away from any unsupported concrete edge.
Professionals and DIY enthusiasts commonly use 1/2"-13 hot dip galvanized wedge anchors for heavy-duty applications. They offer high load-bearing capacity and resistance to corrosion. This makes them a popular choice for securing large items in various projects.
